Motorola CDM Series Basic Service Manual

6-1
Chapter 6
Accessories
6.1 Accessories
To order, contact the Motorola Customer Care and Services Division. For Contact Information, please see
section 1.2.3 on page 2 of Chapter 1, Introduction.
6.1.1 Antennas
VHF (136 -174 MHz)
HAD4006 136 - 144 MHz, 1/4 Wave Roof Mount (Mini U)
HAD4007_R 146 - 150.8 MHz , 1/4 Wave Roof Mount (Mini U)
HAD4008_R 150.8 - 162 MHz, 1/4 Wave Roof Mount (Mini U)
HAD4009_R 162 - 174 MHz, 1/4 Wave Roof Mount (Mini U)
HAD4014_R 146 - 172 MHz, 3dB Gain Roof Mount (Mini U)
UHF 1 (403-470 MHz)
HAE4002 403-430 MHz, 1/4 Wave Roof Mount (Mini U)
HAE4010 406-420 MHz, 3.5 dB Gain Roof Mount (Mini U)
UHF 2 (450-520 MHz) (ferrule connector)
HAE4003_R 450-570 MHz, 1/4 Wave Roof Mount (Mini U)
HAE4004 470-512 MHz, 1/4 Wave Roof Mount (Mini U)
HAE4011_R 450-470 MHz, 3.5 dB Gain Roof Mount (Mini U)
HAE4012 470-494 MHz, 3.5 dB Gain Roof Mount (Mini U)
HAE4013 494 - 512 MHz, 5.0 dB Gain Roof Mount (Mini U)
LowBand 1 (29.7 - 36 MHz)
RAB4002_RB 29.7 - 36 MHz, 1/4 Wave Base Loaded (Mini U)
LowBand 2 (36 - 42 MHz)
RAB4003_RB 36 - 42 MHz, 1/4 Wave Base Loaded (Mini U)
LowBand 3 (42 - 50 MHz)
RAB4004_RB 42 - 50 MHz, 1/4 Wave Base Loaded (Mini U)
