Motorola CDM Series Basic Service Manual

Model Chart and Test Specifications 7-9
7.11 VHF 136-174 MHz (LTR and PassPort)
CDM Series, VHF, 136-174 MHz (LTR and Passport)
Model Description
AAM25KHF9DP5_N
CDM1550·LS
+
, 136-174 MHz, 25W, 16CH
AAM25KHF9DP6_N
CDM1550·LS
+
, 136-174 MHz, 25W, 160CH w/MDC
AAM25KKF9DP5_N
CDM1550·LS
+
, 136-174 MHz, 45W, 16CH
AAM25KKF9DP6_N
CDM1550·LS
+
, 136-174 MHz, 45W, 160CH w/MDC
Item Description
X X X X
GCN6114
CDM1550·LS / CDM1550·LS
+
, Control Head
XXXX
PMLD4288
CDM1550·LS
+
, VHF R1 25W PASSPORT Main Board
X X X X
PMLD4289
CDM1550·LS
+
, VHF R1 45W PASSPORT Main Board
X
PMUD2076A
Tanapa, VHF 136-174 MHz, 25W, 16CH
X
PMUD2077A
Tanapa, VHF 136-174 MHz, 25W, 160CH w/ MDC
X
PMUD2078A
Tanapa, VHF 136-174 MHz, 45W, 16CH
X
PMUD2079A
Tanapa, VHF 136-174 MHz, 45W, 160CH w/ MDC
XXXX
HAD4006
Antenna, 136-144 MHz, ¼ Wave Roof Mount (Mini U)
X X X X
HAD4007
Antenna, 146-150.8 MHz, ¼ Wave Roof Mount (Mini U)
XXXX
HAD4008
Antenna, 150.8-162 MHz, ¼ Wave Roof Mount (Mini U)
X X X X
HAD4009
Antenna, 162-174 MHz, ¼ Wave Roof Mount (Mini U)
XXXX
HAD4014
Antenna, 146-172 MHz, 3dB Gain Roof Mount (Mini U)
X X X X
6881094C79
User Guide, CDM1550.LS / CDM1550.LS
+
“X” Indicates one of each is required.
