Motorola CDM Series Basic Service Manual

7-12 Model Chart and Test Specifications
FCC Description: AZ492FT1627 (40-60W,
29.7-36 MHz)
AZ492FT1628 (40-60W,
36-42 MHz)
AZ492FT1626 (40-60W,
42-50 MHz)
AZ492FT3796 (25W)
AZ492FT3795 (45W)
AZ492FT4835 (25W,
403-470 MHz)
AZ492FT4830 (40W,
403-470 MHz)
AZ492FT4829 (25W,
450-512 MHz)
AZ492FT4836 (40W,
450-512 MHz)
Operating Temperature
-30 to 60
o
C
Storage Temperature
-55 to 85
o
C
Thermal Shock
-40 to 85
o
C
Humidity 95% RH @ 8 Hr.
ESD IEC 801-2 KV
Water Intrusion IP54
Packing Test Impact Test
Transmitter
Specification LowBand VHF UHF
Power Output: 40-60W 1-25W
25-45W
1-25W
25-40W
Conducted/Radiated
Emissions:
-26 dBm -36 dBm < 1 GHz
-30 dBm > 1 GHz
Audio Response: (from 6
dB/oct. Pre-Emphasis, 300
to 3000Hz)
TIA603 and ETS300 /
CEPT 84 Annex 2
Audio Distortion:
@ 1000 Hz, 60%
Rated Maximum Deviation:
3% Typical
Modulation Limiting: ±5.0 kHz ±2.5 kHz @ 12.5 kHz
±4.0 kHz @ 20 kHz
±5.0 kHz @ 25 kHz
FM Hum and Noise: -45 dB -40 dB@12.5 kHz
-45 dB@25 kHz
-40 dB@12.5 kHz
-45 dB@25 kHz
General
Specification LowBand VHF UHF
