Interface Instance
12-17
12.1.12 port-channel

Interface Config Commands
Selects the load-balance criteria of an aggregated port
Supported in the following platforms:
• RFS7000
• RFS4000
Syntax
port-channel load-balance [src-dst-ip|src-dst-mac]
Parameters
Usage Guidelines
Use this command to configure and set load balance on the aggregated port using
(config-if) static-channel-group.
Example
The following example creates a channel group 1, with interface ge1 and ge 2:
RFSwitch(config)#interface ge1
RFSwitch(config-if)#static-channel-group 1
RFSwitch(config)#interface ge2
RFSwitch(config-if)#static-channel-group 1
SWITCH NOTE: RFS6000 does not support this command.
load-balance
[src-dst-ip|src-dst-mac]
Sets load-balancing for port channel
• src-dst-ip – Defines the Source and Destination IP
address based on the current load balancing
• src-dst-mac – Sets the Source and Destination MAC
address based on the load balancing
