NPort 5100 Series User’s Manual Web Console Configuration
5-7
SNMP Settings
Community name
Setting Factory Default Necessity
1 to 39 characters public Optional
A community name is a plain-text password mechanism that is used to weakly authenticate queries
to agents of managed network devices.
Contact
Setting Factory Default Necessity
1 to 39 characters
(E.g., Support, 886-89191230 #300)
None Optional
The SNMP contact information usually includes an emergency contact name and telephone or
pager number.
Location
Setting Factory Default Necessity
1 to 39 characters
(E.g., Floor 1, office 2)
None Optional
Specify the location string for SNMP agents such as NPort 5100. This string is usually set to the
street address where the NPort 5100 is physically located.
IP Address Report
When NPort 5100 products are used in a dynamic IP environment, users must spend more time
with IP management tasks. For example, if NPort 5100 works as a server (TCP or UDP), then the
host, which acts as a client, must know the IP address of the server. If the DHCP server assigns a
new IP address to NPort 5100, the host must have some way of determining NPort 5100’s new IP
address.
NPort 5100 products help out by periodically reporting their IP address to the IP location server, in
case the dynamic IP has changed. The parameters shown below are used to configure the Auto IP
report function. There are two ways to develop an “Auto IP report Server” to receive NPort 5100’s
Auto IP report.
1. Use Device Server Administrator’s IP Address Report function.
2. “Auto IP report protocol”, which can automatically receive the Auto IP report on a regular
basis, is also available to help you develop your own software. Refer to Appendix E for the
“Auto IP report protocol”.
Auto report to IP
Setting Factory Default Necessity
E.g., 192.168.1.1 or URL
(IP addresses of the form x.x.x.0 and
x.x.x.255 are invalid.)
None Optional
Reports generated by the Auto report function will be automatically sent to this IP address.
Auto report to TCP port
Setting Factory Default Necessity
E.g., 4001 4002 Optional
Auto report period
Setting Factory Default Necessity
Time interval (in seconds) 10 Optional
