NPort 5100 Series User’s Manual Configuring NPort Administrator
6-6
2. The Broadcast Search window will open and display the Model, IP Address, MAC Address,
and Progress of the search for that particular device.
3. When the search is complete, the Broadcast Search window will close, and the NPort 5100s
that were located will be displayed in the right pane of the Administrator window. If you
found more than one server connected to this network, refer to the MAC address sticker on
your server(s) to determine which server(s) are the ones you wish to configure. To configure
an NPort 5100, place the cursor over the row displaying that NPort 5100’s information, and
then double click the left mouse button.
ATTENTION
Before modifying the NPort 5100’s configuration, use Broadcast Search to locate all NPort
5100s connected to the LAN, or use Specify by IP Address to locate a particular NPort 5100.
Unlock Password Protection
If the NPort 5100 is password protected (indicated by “Lock” for Status), you will receive the
following error, and you will not be able to use the right click method to open the configuration
page.
In this case, proceed as follows to “Unlock” the device server.
