NPort 5100 Series User’s Manual Web Console Configuration
5-19
If the user wants to send a series of characters in the same packet, the serial device attached to
NPort 5100 should send that series of characters during a time interval less than the Force transmit
timeout for NPort 5100, and the total length of data must be less than or equal to NPort 5100’s
internal buffer size. The serial communication buffer size for NPort 5100 is 1 KB per port.
Destination IP address 1
Setting Factory Default Necessity
IP address or Domain Name
(E.g., 192.168.1.1)
None Required
Allows NPort 5100 to connect actively to the remote host whose IP address is set by this
parameter.
Destination IP address 2/3/4
Setting Factory Default Necessity
IP address or Domain Name
(E.g., 192.168.1.1)
None Required
Allows the NPort 5100 to connect actively to the remote host whose IP address is set by this
parameter.
ATTENTION
Up to 4 connections can be established between the NPort 5100 and hosts. The connection speed
or throughput may be low if one of the four connections is slow, since the 1 slow connection will
slow down the other 3 connections.
ATTENTION
The “Destination IP address” parameter can use both IP address and Domain Name. For some
applications, the user may need to send the data actively to the remote destination domain name.
Designated Local Port 1/2/3/4
Setting Factory Default Necessity
TCP Port No.
5011 (Port 1)
5012 (Port 2)
5013 (Port 3)
5014 (Port 4)
Required
Connection control
Setting Factory Default Necessity
Startup/None, Any Character/None,
Any Character/Inactivity Time,
DSR ON/DSR OFF, DSR ON/None,
DCD ON/DCD OFF, DCD ON/None
Startup/None Required
The meaning of each of the above settings is given in the table below. In general, both the Connect
condition and Disconnect condition are given.
