12 Technical data
109BA6820378-03 EN
Application MTRAB type Silica gel
Phase shifter > 200 MVA DB200D-T or 2x
DB200T
2)
4.4 kg
Reactors ≤ 40 MVAr DB100T 1.1 kg
Reactors > 40 Mvar
≤ 200 Mvar
DB200T 2.2 kg
Reactors > 200 MVAr DB200D-T or 2x
DB200T
2)
4.4 kg
High voltage DC transmission
(HVDCT) transformers
DB200D-T or 2x
DB200T
2)
4.4 kg
Furnace transformers DB200G 4.4 kg
Underground hall transformers DB200G 4.4 kg
GSU machine transformers DB200G 4.4 kg
MTRAB type Heating current
1)
Silica gel Control
3)
U
V
=
120V
U
V
= 230V
DB100 1.2A 0.6A 1.1 kg Alpha
DB100T 1.2A 0.6A 1.1 kg Beta
DB200T 2.3A 1.2A 2.2 kg Beta
DB200D-T 4.7A 2.4A 4.4 kg Beta
DB200G 2.3A 1.2A 4.4 kg Gamma
1) Heating current during the heating process (approx. 1-2 min. After heating
activation).
2) Mount individually on the conservator tank, no parallel mounting (see
mounting recommendations).
3) Alpha control: Status-dependent control of the heat-drying process
through humidity monitoring.
Beta controller (suffix T in the type designation): Self-learning system
with status-dependent control of the heat-drying procedure through humidity
monitoring and temperature-dependent determination of the most advanta-
geous time to perform heat-drying.
Gamma controller: System for applications with non-periodic breathing be-
havior. By monitoring the air humidity, the dehydrating cylinders are alter-
nately regenerated based on status.
