MR MESSKO MTRAB - Mounting the Device on the Counterflange

5 Mounting
39BA6820378-03 EN
5. For lifting the DB100 / DB200, replace the grounding screw with a lifting
eye bolt.
Figure19: Lifting eye bolt
5.4 Mounting the device on the counterflange
WARNING
Danger of death and damage to property!
Danger of death and damage to property due to falling load!
► Do not walk under the suspended load.
► Use a means of transport and lifting gear with sufficient carrying capac-
ity.
NOTICE
Malfunction!
The connection may not be correctly sealed if there is grease on the flange
contact surfaces.
► Ensure that the flange contact surfaces are clean and free of grease
when mounting.
