5 Mounting
38 BA6820378-03 EN
NOTICE
Danger of damage to property
If a flange is used that is unsuitable for the weight of the device, the flange
may fail.
► Only use the 2-hole RM flange for the DB100.
Figure17: Insertion of MTRAB flange
4. Screw the flange onto the MTRAB by hand (approx. 1Nm).
Figure18: Screwing on the flange
