MR MESSKO MTRAB - Terminal Box and Status Indicators

3 Product description
22 BA6820378-03 EN
3.4 Terminal box
Figure3: Connection box
1 LEDs for status display 2 RTC buffer battery (type CR2032)
3 USB service interface 4 Test button
5 Modbus settings (optional) 6 Fuse
7 Supply voltage
100...127V DC / AC 50/60Hz
200...240V DC / AC 50/60Hz
8 Cable gland
M20x1.5 (brass/stainless steel) or
1/2″ 14NPT (brass)
