4 Packaging, transport and storage
31BA6820378-03 EN
To remove the DB200D / DB200G dehydrating breather from the packaging,
proceed as follows:
1. Grasp the connection pipe and both air exhausts on the DB200D /
DB200G as shown in the image.
Figure7: DB200D / DB200G removal
2. Work in pairs to remove the DB200D / DB200G from the shipping con-
tainer.
3. Place the dehydrating breather on a flat surface. Ensure that the glass
cylinder of the desiccant container is exposed.
NOTICE
Damage to the dehydrating breather
The device can become damaged or fall if it is set down vertically on the air
exhaust.
► Do not support or set the device down on the air exhaust.
► Always set the device down horizontally.
► Hold the DB100/DB200 firmly and secure it against turning.
