OperationMSA
ALTAIR 4X
GB
27
Toxic Gas Units
Name of Toxic Gas Units displays [ppm or mg/m
3
].
NOTE: Toxic units can only be modified through the MSA Link soft-
ware.
Alarm Set points
Alarm set points for all installed and activated sensors display.
LOW alarm set points display, followed by HIGH alarm set points.
NOTE: Alarm set points can be changed manually through the
Setup menu or the MSA Link software.
STEL and TWA Set points
The preset STEL and TWA values for installed and activated sen-
sors display.
H2S
CO
COMB/EX
O2
H2S
CO
COMB/EX
O2
H2S
CO
CO
H2S
CO
