5 Installation
US FL5000 Multi-Spectrum Flame Detector 35
Position
1 2 3 4 5 6 7 8 9 10 11 12
High Sensitivity OFF OFF - - - - - - - - - -
Medium Sensitivity ON OFF - - - - - - - - - -
Low Sensitivity OFF ON - - - - - - - - - -
0 Sec Alarm Time Delay - - ON ON - - - - - - - -
8 Sec Alarm Time Delay - - OFF ON - - - - - - - -
10 Sec Alarm Time Delay - - OFF OFF - - - - - - - -
14 Sec Alarm Time Delay - - ON OFF - - - - - - - -
Sustained Alarm Non-Latching - - - - OFF - - - - - - -
Sustained Alarm Latching - - - - ON - - - - - - -
Instant Alarm Non-Latching - - - - - OFF - - - - - -
Instant Alarm Latching - - - - - ON - - - - - -
Sustained Alarm Normal De-Energized - - - - - - OFF - - - - -
Sustained Alarm Normal Energized - - - - - - ON - - - - -
Instant Alarm Normal De-Energized - - - - - - - OFF - - - -
Instant Alarm Normal Energized - - - - - - - ON - - - -
LEDs - StandardMode - - - - - - - - OFF - - -
LEDs - Alternate PEMEXMode - - - - - - - - ON - - -
HARTEnabled - - - - - - - - - OFF - -
HARTDisabled - - - - - - - - - ON - -
Window Heater Disabled - - - - - - - - - - OFF -
Window Heater Enabled - - - - - - - - - - ON -
Test Lamp AOMode Disabled - - - - - - - - - - - OFF
Test Lamp AOMode Enabled - - - - - - - - - - - ON
BLE Enabled ON
BLE Disabled OFF
AOSink Sink
AOSource Source
5.7.1 Time Delay Settings
When set to a minimum of 8 seconds, Time delay set via dipswitch guarantees that FL5000 will not go into SUSTAINED
ALARM mode (20 mA) if the flame source is removed within 50% of set delay time from the start of flame. The unit will go
into INSTANT ALARM mode (16 mA) upon seeing a flame source.
