40 FL5000 Multi-Spectrum Flame Detector US
7 Troubleshooting
7.1 Final Assembly
Figure 21 FL5000 Cross-Section View
1 Sapphire Window 8 Mounting Pin
2 EMI Screen 9 Modular Power Board
3 Heater Ring Board 10 Modular Communication Board
4 Label 11 Modular Processor Board
5 O-Ring 12 Analog Board
6 Base Housing 13 Optical Housing Assembly
7 Field Wiring Board
