MSA GM FL5000 - False Alarm Stimuli Performance

76 FL5000 Multi-Spectrum Flame Detector US
9 Certifications
9.1.3 False Alarm Stimuli Performance
The FMapproved FL5000 detector is immune to a variety of false alarm sources. Below are representative samples of
detector response in the presence of false stimuli.
As a worst case condition the high sensitivity variation was tested to demonstrate no false alarm result without fuel
n-Heptane (1' x 1'), equivalent to 0.3 x 0.3 meters. This generated the following:
False Alarm Source
(Modulated and Un-modulated)
False Alarm
Distance from
Detector
ft (m)
n-Heptane (1' x 1')
Fuel Distance
from Detector
ft (m)
Response Time for
Instant Alarm:
Sustained Alarm
(seconds)
Hand Wave 0.5 (0.15) --- ---
Sunlight, Direct --- --- ---
Sunlight, Reflected, Un-modulated @ 3’ --- 90 (27) 16 : 17
Sunlight, Reflected, Modulated @ 10’ --- 40 (12) 6 : 7
Sunlight, Reflected, Modulated @ 5’ --- 30 (9) 6 : 7
Arc Welding, 200A AC, 7014 rod 10 (3) 80 (24) 9 : 10
Arc Welding, 200A DC+, 7014 rod 10 (3) 80 (24) 6 : 7
Arc Welding, 200A DC-, 7014 rod 10 (3) 80 (24) 7 : 8
Arc Welding, 200A AC, 6012 rod 10 (3) 80 (24) 7 : 8
Arc Welding, 200A DC+, 6012 rod 10 (3) 80 (24) 7 : 8
Arc Welding, 200A DC-, 6012 rod 10 (3) 80 (24) 6 : 7
Arc Welding, 200A AC, 6011 rod 10 (3) 80 (24) 8 : 8
Arc Welding, 200A DC+, 6011 rod 10 (3) 80 (24) 7 : 8
Arc Welding, 200A DC-, 6011 rod 10 (3) 80 (24) 6 : 7
1500W Electric Radiant Heater (Lakewood), Un-modulated 12 (3.3) 80 (24) 10 : 11
1500W Electric Radiant Heater (Sear), Un-modulated 12 (3.3) 80 (24) 10 : 11
1500W Electric Radiant Heater (Sears), Modulated 10 (3) 60 (18) 14 : 15
6kW Electric Radiant Heater, Un-modulated (Data Set #1) 18 (5.5) 60 (18) 8 : 9
6kW Electric Radiant Heater, Modulated (Data Set #1) 20 (6) 60 (18) 7 : 8
6kW Electric Radiant Heater, Un-modulated (Data Set #2) 10 (3) 80 (24) 11 : 12
6kW Electric Radiant Heater, Modulated (Data Set #2) 50 (15) 80 (24) 7 : 7
300W Clear Incandescent Lamp 10 (3) 80 (24) 6 : 7
100W Frost Incandescent Lamp 2.5 (0.8) 80 (24) 7 : 8
25W Clear Incandescent Lamp 1 (0.3) 80 (24) 8 : 9
2-30W Fluorescent Lamps, Un-modulated 1 (0.3) 80 (24) 7 : 8
2-30W Fluorescent Lamps, Modulated 2 (0.6) 80 (24) 7 : 8
100,000 lux LED Flash Light 5 (1.5) 80 (24) 7 : 8
100W UV Blacklight Lamp 10 (3) 80 (24) 7 : 8
70W Sodium Lamp 10 (3) 80 (24) 6 : 7
250W Sodium Lamp 10 (3) 80 (24) 8 : 9
