9 Certifications
US FL5000 Multi-Spectrum Flame Detector 77
False Alarm Source
(Modulated and Un-modulated)
False Alarm
Distance from
Detector
ft (m)
n-Heptane (1' x 1')
Fuel Distance
from Detector
ft (m)
Response Time for
Instant Alarm:
Sustained Alarm
(seconds)
150W Shielded Mercury Lamp 10 (3) 80 (24) 6 : 7
500W Shielded Halogen Lamp, Un-modulated 10 (3) 80 (24) 6 : 7
500W Shielded Halogen Lamp, Modulated 15 (4.5) 80 (24) 11 : 12
500W Unshielded Halogen Lamp, Un-modulated 10 (3) 80 (24) 6 : 7
500W Unshielded Halogen Lamp, Modulated 15 (4.5) 80 (24) 12 : 12
200C Hot Plate, Un-modulated 15 (4.5) 80 (24) 6 : 7
200C Hot Plate, Modulated 15 (4.5) 80 (24) 14 : 15
