Connecting and configuring external devices
Connecting sensors to the terminal
6
1. - Open the “Service” application.
2. Tap "Driver".
3. Tap “Auxiliary”.
4. Mark “Auxiliary2”.
5.
- Confirm.
6. Restart the terminal.
To configure the button assignment:
You have activated the “Auxiliary2” driver
1.
- Open the “Service” application.
2. Tap “Auxiliary”.
3. Tap “Auxiliary Editor”.
⇨ If the ISOBUS job computer supports the Auxiliary 2 protocol, a list appears of the job
computer functions.
⇨ If no list appears, the ISOBUS job computer does not support this protocol.
4. Tap the function which you want to assign to this button on the joystick.
⇨ A list of the buttons on the joystick appears.
⇨ You have two options for assigning the function to the joystick.
5. Option 1: On the joystick, press the button to which you want to assign the function.
Option 2: On the terminal, select the button to which the selected function should be assigned
and confirm with
.
⇨ The function will be assigned to the button and you can continue with the next function, until
you have assigned all of the functions.
6. Restart the terminal.
⇨ After restarting, the following notification appears on the main terminal screen: “Confirm the
assignments.” This notification appears after any restart.
7. “OK” - acknowledge the notification.
⇨ A list of recognized assignments appears on the terminal screen.
8.
- Confirm the assignments.
Connecting sensors to the terminal
The terminal provides you with the possibility of connecting a sensor or the tractor's 7-pin signal
socket to port B. This allows you for example to use the work position signal in the TRACK-Leader
parallel guide.
The work position sensor sold by Müller-Elektronik is fitted with a round 3-pin connector. You will
need an adapter cable to connect it to the terminal.
