Tractor-ECU application
Parameter
8
30322538-02-EN
V9.20191001
57
A Distance between the centre of the vehicle and the GPS receiver, on the left-right axis.
If the receiver is installed on the left side, enter a negative value.
Users of TRACK-Leader AUTO®: The position of the GPS receiver must also be entered and
calibrated in the steering job computer. For this reason, the A and B boxes are greyed-out and cannot
be edited.
B
Distance between the GPS receiver and the rear axle of the vehicle.
C
Distance between the rear axle and the rear mounting or attachment point.
E
Distance between the rear axle and the front mounting or attachment point.
Configuring the tractor connector types
The connector type can differ among various tractors and mounted or trailed implements. Per default,
the connector type is always set to “Unknown”.
Please note that when you select a different connector type or multiple different connector types, the
automatic list of connections no longer works. You then have to list the connections manually.
The following connector types are possible:
▪ Unknown
▪ Drawbar
▪ 3-point hitch mounted
▪ 3-point hitch semi-mounted
▪ Hitch hook
▪ Clevis coupling
▪ Piton-type coupling
▪ CUNA hitch
▪ Ball-type hitch
Function icon
Meaning
Adds a new connector type.
Deletes the marked connector type.
Edits the marked connector type.
1. - Open the Tractor ECU application.
2. Tap “Settings”.
⇨ The existing tractor profiles appear.
⇨ If a tractor profile is activated, most of the other function icons are greyed-out.
3.
- To edit a tractor profile or to create a new one, you must deactivate the activated tractor
profile.
4. Tap on the tractor profile to be edited.
5.
- Call up the parameter list.
⇨ The parameters are displayed.
Procedure
