Technical specifications
Technical specifications of the terminal
12
30322538-02-EN
V9.20191001
79
Technical specifications
Technical specifications of the terminal
Operating voltage
10V - 32V
Current consumption
(operation)
0.5A (typical) - 4A
Power input
Typical: 6W
Maximum: 40W
Ambient temperature
-20°C - +60°C
Storage temperature
-30°C - +80°C
Dimensions (W x H x D)
243mm x 186mm x 69mm
Weight
1.1kg
Protection class
IP6K4 according to ISO 20653:2013
EMC
ISO 14982
ESD protection
ISO 10605:2001 Level IV
Environmental testing Vibration:
ISO 15003 Level 1 with Level 2 temperature overlap in accordance
with ISO 15003
Shock:
100 shocks per axis and direction with 15g and 11ms in accordance
with IEC 60068-2-27
Processor
i.MX 515 600MHz
Coprocessor
STM32F205
Storage
256M mDDR
Bootflash
128M SCL-NAND-Flash
Operating system
WinCE 6.0
Display
8'' SVGA TFT
Housing
PC-ABS
Inputs / outputs 1 x USB
1 x Sub-D 9 socket (CAN and power supply)
