User Manual
In CAN bus trigger mode, the trigger setting information is displayed on bottom
right of the screen, for example, ，indicates that trigger
type is CAN, CH1 trigger level is -126 mV.
CAN Trigger menu list:
Set vertical channel bus type as CAN trigger.
Select CH1 as the trigger source.
Select CH2 as the trigger source.
Select CH3 as the trigger source.
Select CH4 as the trigger source.
Actual CAN_H bus signal.
Actual CAN_L bus signal.
Transmission signal on the CAN signal line.
Received signal on the CAN signal line.
Turn the M rotary control (or tap on in touchscreen)
to set the Sample point, which is a point within a bit’s
time. The oscilloscope samples the bit level at this point.
“Sample point” is represented by the percentage of “the
time from the start of the bit’s time to the sample point
time” in the “bit’s time”. The range is 5% to 95%.
Turn the M rotary control to select from the Baud list on
the left.
Turn the M rotary control (or tap on in touchscreen)
to set the Baud. The range is 10,000 to 1,000,000.
Tip: You can select the nearest value in Common Baud,
and then adjust it in this menu.
Trigger on the start frame of the data frame.
Trigger on the selected frame.
Select Standard or Extended.
Use the M rotary control and
Direction key on the front panel
to set.
To Next Page
