11. Technical Specifications
Unless otherwise specified, the technical specifications applied are for XDS3000
four-channel series only, and Probes attenuation set as 10X. Only if the oscilloscope
fulfills the following two conditions at first, these specification standards can be
reached.
 This instrument should run for at least 30 minutes continuously under the
specified operating temperature.
 If change of the operating temperature is up to or exceeds 5℃, do a
"Self-calibration" procedure (see "How to Implement Self-calibration" on P14).
All specification standards can be fulfilled, except one(s) marked with the word
"Typical".
Oscilloscope
Performance Characteristics
Instruction
Bandwidth
MP720025
MP720021
100 MHz
Vertical Resolution (A/D)
MP720025
8 bits
MP720021
8 bits
Channel
4
Waveform Capture Rate
MP720025
45,000 wfms/s
MP720021
70,000 wfms/s
Multi-level Gray Scale Display &
Color Temperature Display
(Use gray scale to indicate frequency of
occurrence, where frequently occurring
waveform are bright.)
Support
Magnifier Function
(The magnifier window can display the
magnified wave of the wave selection
horizontally and vertically.)
MP720025
MP720021
Not support
Acquisition
Mode
Normal, Peak detect, Averaging
Sample rate
(real time)
MP720025
Four CH
250 MSa/s
Dual CH*
500 MSa/s
Single CH
1 GSa/s
MP720021
Four CH
500 MSa/s
Dual CH*
1 GSa/s
Single CH
1 GSa/s
Input
Input coupling
DC, AC , Ground
Input impedance
1 MΩ±2%, in parallel with 15 pF±5 pF
