User Manual
7. Communication with PC
The oscilloscope supports communications with a PC through USB, LAN port or Wi-Fi.
You can use the Oscilloscope communication software to store, analyze, display the data
and remote control.
To learn about how to operate the software, you can push F1 in the software to open the
help document.
Here is how to connect with PC. First, install the Oscilloscope communication software on
the supplied CD. Then there are several ways of connection to choose from.
Using USB Port
(1) Connection: Use a USB data cable to connect the USB Device port in the right panel
of the Oscilloscope to the USB port of a PC.
(2) Install the driver: Run the Oscilloscope communication software on PC, push F1 to
open the help document. Follow the steps of title "I. Device connection" in the
document to install the driver.
(3) Port setting of the software: Run the Oscilloscope software; click
"Communications" on the menu bar, choose "Ports-Settings", in the setting dialog,
choose "Connect using" as "USB". After connect successfully, the connection
information in the bottom right corner of the software will turn green.
Figure 7-1 Connect with PC through USB port
