multicomp pro MP720025 User Manual

User Manual
143
Counter
Support
* For MP720025, Max Sample rate (real time) for Dual CH should meet either following
condition:
 CH1&CH2 on, CH3&CH4 off;
 CH1&CH2 off, CH3&CH4 on.
* For MP720021, Max Sample rate (real time) for Dual CH should meet the following
condition:
CH1 and CH2 can not be turned on simultaneously, CH3 and CH4 can not be turned
on simultaneously.
 CH1&CH3 on, the others off;
 CH1&CH4 on, the others off;
 CH2&CH3 on, the others off;
 CH2&CH4 on, the others off.
Trigger
Performance Characteristics
Instruction
Trigger level range
Internal
±5 div from the screen center
Trigger level
Accuracy (typical)
Internal
±0.3 div
Trigger
displacement
According to Record length and time base
Trigger Holdoff
range
100 ns – 10 s
50% level setting
(typical)
Input signal frequency ≥ 50 Hz
Edge trigger
Slope
Rising, Falling
Video Trigger
Modulation
Support standard NTSC, PAL and
SECAM broadcast systems
Line number range
1-525 (NTSC) and 1-625 (PAL/SECAM)
Pulse trigger
Trigger condition
Positive pulse：＞, ＜, ＝
Negative pulse：＞, ＜, ＝
Pulse Width range
30 ns to 10 s
Slope Trigger
Trigger condition
Positive pulse：＞, ＜, ＝
Negative pulse：＞, ＜, ＝
Time setting
30 ns to 10 s
Runt Trigger
Polarity
Positive, Negative
Pulse Width
Condition
>, =, <
Pulse Width Range
30 ns to 10 s
Windows Trigger
Polarity
Positive, Negative
Trigger Position
Enter, Exit, Time
Windows Time
30 ns to 10 s
Timeout Trigger
Edge Type
Rising, Falling
