Select "ON" to display the event table.
If a USB storage device is currently connected to the
instrument, save the event table data in a .csv
(spreadsheet) formatted file on the external USB storage
device.
Select "ON" to display the ASCII table.
How to Operate the Function Menu
The function menu control zone includes 8 function menu buttons: Measure, Acquire,
Utility, Cursor, Autoscale, Save, Display, Help and 3 immediate-execution buttons:
Autoset, Run/Stop, Single.
How to Implement Sampling Setup
Push the Acquire button, Acqu Mode, Length, PERF Mode (only for the
oscilloscope with A in the model name) and Intrpl is shown in the bottom menu.
The description of the Acqu Mode menu is shown as follows:
Use to capture maximal and minimal
samples. Finding highest and lowest points
over adjacent intervals. It is used for the
detection of the jamming burr and the
possibility of reducing the confusion.
It is used to reduce the random and don't-care
noises, with the optional number of averages.
The description of the Record Length menu is shown as follows:
Choose the record length
Note: When four channels are turned on, the
max record length is 10M; and max 20M
for two channels; max 40M for one
channel.
