Performance Characteristics
Instruction
Input coupling
0.001X - 1000X, step by 1 – 2 - 5
Max input voltage
400 V (DC + AC Peak)
Bandwidth limit
20 MHz, full bandwidth
Channel –channel
isolation
50Hz: 100 : 1
10MHz: 40 : 1
Time delay between
channel(typical)
150ps
Horizontal
System
Sampling rate range
MP720025
Four CH
0.05 Sa/s -
250 MSa/s
Dual CH*
0.05 Sa/s -
500 MSa/s
Single CH
0.05 Sa/s -
1 GSa/s
MP720021
Four CH
0.05 Sa/s -
500 MSa/s
Dual CH*
0.05 Sa/s -
1 GSa/s
Single CH
0.05 Sa/s -
1 GSa/s
Interpolation
(Sinx)/x, x
Max Record length
When four channels are turned on, the max
record length is 10M; and max 20M for two
channels; max 40M for one channel.
Scanning speed (S/div)
MP720025
2ns/div - 1000s/div,
step by 1 – 2 - 5
MP720021
1ns/div - 1000s/div,
step by 1 – 2 - 5
Sampling rate / relay
time accuracy
±2.5 ppm max (Ta = +25℃)
Interval(△T) accuracy
(DC - 100MHz)
Single：
±(1 interval time+1 ppm×reading+0.6 ns);
Average>16：
±(1 interval time +1 ppm×reading+0.4 ns)
Vertical system
Sensitivity
1 mV/div - 10 V/div
Displacement
MP720025
±2 V (1 mV/div – 50 mV/div)；
±20 V (100 mV/div – 1 V/div)；
±200 V (2 V/div – 10 V/div)
MP720021
±2 V (1 mV/div – 100 mV/div)；
±20 V (200 mV/div – 1 V/div)；
±200 V (2 V/div – 10 V/div)
