PAGE 78 — GENERATOR SERVICE AND TROUBLESHOOTING MANUAL — REV. #0 (08/29/23)
ECU
-
845 AC FAULT CODES
Table 10. ECU-845 AC Defaults (John Deere)
Setpoint Defaults
J4FSA :
DCA70SSJU4F
J4FSB :
DCA180SSJU4F
J4FSC :
DCA300SSJU4F2
J4FSD :
DCA150SSJU4F2
J4FSE :
DCA220SSJU4F2
Menu Structure J4FSA 0-11-0-17 J4FSB 0-11-0-17 J4FSC 0-11-0-17 J4FSD 0-11-0-17 J4FSE 0-11-0-17
|-> AC MISC SETTINGS
|-> AC HIGH HZ % 110 110 110 110 110
|-> AC HIGH HZ SECONDS 3 3 3 3 3
|-> AC LOW HZ % 90 90 90 90 90
|-> AC LOW HZ SECONDS 5 5 5 5 5
|-> AC GLOBAL ENABLE 1 1 1 1 1
|-> AC IDLE REENABLE SECS 5 5 5 5 5
|-> AC SIGNIFICANT KVA % 25 25 25 25 25
|-> AC AMPS THRESHOLD 10 10 15 10 10
|-> PHASE CFG DWELL SEC 5 5 5 5 5
|-> PHASE CFG TIMEOUT SEC 10 10 10 10 10
|-> VOLT AND AMP SETPOINTS
|-> AC HIGH VOLTS % 110 110 110 110 110
|-> AC HIGH VOLTS SECONDS 5 5 5 5 5
|-> AC LOW VOLTS% 75 75 75 75 75
|-> AC LOW VOLTS SECONDS 5 5 5 5 5
|-> AC HIGH AMPS % 115 115 115 115 115
|-> AC HIGH AMPS SECONDS <DISABLED> 000030 <DISABLED> 000030 <DISABLED> 000030 <DISABLED> 000030 <DISABLED> 000030
|-> KW AND KVAR SETPOINTS
|-> AC HIGH KW % 115 115 115 115 115
|-> AC HIGH KW SECONDS 14 14 14 14 14
|-> AC LOW KW % -15 -15 -15 -15 -15
|-> AC LOW KW SECONDS <DISABLED> 000010 <DISABLED> 000010 <DISABLED> 000010 <DISABLED> 000010 <DISABLED> 000010
|-> AC LOW PF VALUE 35 35 35 35 35
|-> AC LOW PF SECONDS <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014
|-> AC HIGH KVA % 110 110 110 110 110
|-> AC HIGH KVA SECONDS <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014
|-> AC HIGH KVAR % 140 140 140 140 140
|-> AC HIGH KVAR SECONDS <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014
|-> AC LOW KVAR % -55 -55 -55 -55 -55
|-> AC LOW KVAR SECONDS <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014 <DISABLED> 000014
|-> RATINGS 60HZ
|-> KW RATING OF SET 56 144 240 120 176
|-> SINGLE PHASE SETTINGS
|-> SNGL PH RATED VOLTS LL 240 240 240 240 240
|-> SNGL PH RATED VOLTS LN 120 120 120 120 120
|-> SNGL RATED PHASE AMPS 168 433 722 361 529
|-> SNGL RATED PHASE KVA 20 52 87 43 63
|-> SNGL RATED PHASE KW 20 52 87 43 63
|-> SNGL RATED PHASE KVAR 20 52 87 43 63
|-> LOW WYE SETTINGS
|-> LO WYE RATED VOLTS LL 240 240 240 240 240
|-> LO WYE RATED VOLTS LN 139 139 139 139 139
|-> LO WYE RATED PHASE AMP 168 433 722 361 529
|-> LO WYE RATED PHASE KVA 23 60 100 50 73
|-> LO WYE RATED PHASE KW 19 48 80 40 59
|-> LO WYE RATED PHASE KVAR 14 36 60 30 44
