GENERATOR SERVICE AND TROUBLESHOOTING MANUAL — REV. #0 (08/29/23) — PAGE 79
ECU
-
845 AC FAULT CODES
Table 10. ECU-845 AC Defaults (John Deere)
Setpoint Defaults
J4FSA :
DCA70SSJU4F
J4FSB :
DCA180SSJU4F
J4FSC :
DCA300SSJU4F2
J4FSD :
DCA150SSJU4F2
J4FSE :
DCA220SSJU4F2
Menu Structure J4FSA 0-11-0-17 J4FSB 0-11-0-17 J4FSC 0-11-0-17 J4FSD 0-11-0-17 J4FSE 0-11-0-17
|-> HIGH WYE SETTINGS
|-> HI WYE RATED VOLTS LL 480 480 480 480 480
|-> HI WYE RATED VOLTS LN 277 277 277 277 277
|-> HI WYE RATED PHASE AMPS 84 217 361 180 265
|-> HI WYE RATED PHASE KVA 23 60 100 50 73
|-> HI WYE RATED PHASE KW 19 48 80 40 59
|-> HI WYE RATED PHASE KVAR 14 36 60 30 44
|-> RATINGS 50HZ
|-> KW RATING OF SET 44 120 216 100 160
|-> SINGLE PHASE SETTINGS
|-> SNGL PH RATED VOLTS LL 200 200 200 200 200
|-> SNGL PH RATED VOLTS LN 100 100 100 100 100
|-> SNGL RATED PHASE AMPS 159 433 779 361 577
|-> SNGL RATED PHASE KVA 16 43 78 36 58
|-> SNGL RATED PHASE KW 16 43 78 36 58
|-> SNGL RATED PHASE KVAR 16 43 78 36 58
|-> LOW WYE SETTINGS
|-> LO WYE RATED VOLTS LL 200 200 200 200 200
|-> LO WYE RATED VOLTS LN 115 115 115 115 115
|-> LO WYE RATED PHASE AMP 159 433 779 361 577
|-> LO WYE RATED PHASE KVA 18 50 90 42 67
|-> LO WYE RATED PHASE KW 14 40 72 34 53
|-> LO WYE RATED PHASE KVAR 11 30 54 25 40
|-> HIGH WYE SETTINGS
|-> HI WYE RATED VOLTS LL 400 400 400 400 400
|-> HI WYE RATED VOLTS LN 231 231 231 231 231
|-> HI WYE RATED PHASE AMPS 79 217 390 180 289
|-> HI WYE RATED PHASE KVA 18 50 90 42 67
|-> HI WYE RATED PHASE KW 14 40 72 34 53
|-> HI WYE RATED PHASE KVAR 11 30 54 25 40
