Video Grabber DGR-1000 User Manual - v. 1.4 (FW 1.9)
78
5.5.11. confDpVideo (subsection 12)
In the following table only OBJECTNUMBER part of the identifier (OID) is listed.
OBJECTNUMBER
Name
Access
Type
Description
1
retrainDp
read-write
Integer
Write 1 to retrain DisplayPort
link.
Example:
To retrain the DisplayPort link on the Video Grabber with IP address 192.168.5.2 one would have to
run the following commands:
First write 1 on the retrainDp field:
snmpset –v3 –l authPriv –u rw_user
-a MD5 –A uXTxzFQOscIZR1qcMAOSEwxf2HDeD6
-x DES –X LlUzFSpOVmBrem3VOFYfqd42VB1vve
192.168.5.2 1.3.6.1.4.1.46236.1.3.12.1.0 i 1
Then apply the settings:
snmpset –v3 –l authPriv –u rw_user
-a MD5 –A uXTxzFQOscIZR1qcMAOSEwxf2HDeD6
-x DES –X LlUzFSpOVmBrem3VOFYfqd42VB1vve
192.168.5.2 1.3.6.1.4.1.46236.1.3.11.1.0 i 4321
