Video Grabber DGR-1000 User Manual - v. 1.4 (FW 1.9)
24
4.2. Configuration page
Configuration page allows user to configure the Video Grabber. Here user can change its IP addresses,
decide on the way in which the captured video should be processed (protocol, format) and set the
time synchronization.
Access to the Configuration page is password-protected. The login details are as follows:
Username: grabber
Password: vgbr2014
ID
Section
Description
1
General
Basic settings related to the built-in OLED screen
See 4.2.1, p. 26
2
Network
LAN 1 and LAN 2 related settings
See 4.2.2, p. 27
3
Video
Video capture and processing related settigns such as protocol, format
etc.
See 4.2.3, p. 29
4
NTP
Time synchronization (NTP) related settings
See 4.2.4, p. 42
5
Commands
Command buttons
See 4.2.5, p. 43
Table 11: Description of the sections available on the Configuration page
