4.2.2.1. IP address
Video Grabber is equipped with two independent Ethernet interfaces. Both can be configured
individually. See the table below for details. Identification numbers (first column) refer to the
parameter’s position on the Figure 25.
Settings for LAN1
No
Name
Description
Allowed values
1
IP Address
IPv4 address for the LAN1 in the xxx.xxx.xxx.xxx
format. Should be different than the one set for
LAN2
Example:
192.168.1.44
Valid IPv4 address
Prohibited ranges:
127.xxx.xxx.xxx
0.xxx.xxx.xxx
224.xxx.xxx.xxx
2
Subnet Mask
Subnet mask for the LAN1 in the xxx.xxx.xxx.xxx
format.
Example:
255.255.255.0
Valid IPv4 netmask
Prohibited values:
0.0.0.0
255.255.255.255
Settings for LAN2
No
Name
Description
Allowed values
9
IP Address
IPv4 address for the LAN2 in the xxx.xxx.xxx.xxx
format. Should be different than the one set for
LAN1
Example:
192.168.2.44
Valid IPv4 address
Prohibited ranges:
127.xxx.xxx.xxx
0.xxx.xxx.xxx
224.xxx.xxx.xxx
10
Subnet Mask
Subnet mask for the LAN1 in the xxx.xxx.xxx.xxx
format.
Example:
255.255.255.0
Valid IPv4 netmask
Prohibited values:
0.0.0.0
255.255.255.255
