MULTISOFT VGR-1000 - Page 9

Video Grabber User Manual - v. 1.19 (FW 1.29)
9
Analogue
Resolution (width x height)
Signal refresh rate
Cables
640 x 480 (VGA)
75Hz
DVI-I (Dual Link)
DVI-I (Single Link)
DVI-A
D-SUB
2
720 x 400
70Hz
800 x 600 (SVGA)
75Hz
832 x 624
75Hz
1024 x 768 (XGA)
75Hz
1152 x 870
75Hz
1280 x 720 (HD 720)
60Hz
1280 x 1024 (SXGA)
75Hz
1440 x 900
60Hz
1600 x 1200 (UXGA)
60Hz
1920 x 1080 (HD 1080)
60Hz
1920 x 1200 (WUXGA)
60Hz
Digital
Resolution (width x height)
Signal refresh rate
Cables
640 x 480 (VGA)
60Hz
DVI-D (Dual Link)
3
DVI-D (Single Link)
800 x 600 (SVGA)
60Hz
1024 x 768 (XGA)
60Hz
1280 x 720 (HD 720)
60Hz
1280 x 800 (WXGA)
60Hz
1280 x 1024 (SXGA)
60Hz
1600 x 900
60Hz
1680 x 1050 (WSXGA+)
60Hz
1920 x 1080 (HD 1080)
60Hz
1920 x 1200 (WUXGA)
60Hz
2048 x 2048
60Hz
DVI-D (Dual Link)
2560 x 1440 (WQHD)
60Hz
2560 x 1600 (WQXGA)
60Hz
3840 x 2160 (UHD-1)
30Hz
Please note that the rate at which the signal is captured will usually be much lower than the actual
signal refresh rate. For details on setting the signal capture rate see 4.2.1.2 on page 21.
2
When using D-SUB cables it is necessary to use D-SUB to DVI-I converters
3
Some video cards generate noise on the unused link when working on Single Link resolution. To avoid such
problems use DVI-D (Single Link) cables when working with single link resolutions.
