Getting Acquainted with Your Machine1-4
Part Names
The following drawings illustrate the parts of your machine referred to
throughout this guide, so please take some time to become familiar with
them.
Front View
1—Control panel
2—Automatic Document
Feeder (ADF)
2-a: ADF feed cover
2-b: Document guide
2-c: Document feed tray
2-d: Document output tray
2-e: Document stopper
" Lower the document
stopper when scanning
Legal-size paper with
the ADF.
3—USB HOST port
" A USB hub can be con-
nected to the USB
HOST port. In addition,
a USB memory device
and an authentication
device (IC card type)
can be connected to
the USB hub at the
same time.
4—Tray 1 (Manual feed tray)
5—Tray 2
6—Output tray
7—Scanner lock lever
8—Original glass
9—Original cover pad
10—Scanner unit
10
9
6
7
8
4
3
2-e
2
2-c
2-d
5
1
2-a
2-b
