Touch panel screens 2-13
Keys and icons that appear in the screens
Icon Description
If the screen has multiple pages, press [ ] or [ ] to select a dif-
ferent page.
If values appear between [ ] and [ ], the current page num-
ber/total number of pages is indicated.
If there are tabs that are not displayed, press [ ] or [ ] to
select a different tab.
Press to adjust the image quality during a copy, scan or fax
operation.
Press [+] or [-] to change the entered value.
Press to view the error message when an error occurs.
Press to display descriptions of the various functions.
A description of the current screen will be displayed.
Press to display the address book. From this screen, you can
select single destinations and group destinations registered in
the address book.
Press to return to the home screen.
Appears while scanning and printing when making copies.
Appears while scanning with fax transmission and scanning
operations.
