Handling the printer
RJ-900X series OPERA
TION MANUAL
4-8
4.3
Media eject tray setting
The setting procedure of media eject tray (optional) is described.
The media eject tray supplie
d with the dedicated stand can be used
to eject media smoot
hly by preventing
the printed media from spotting or folding.
1.
Pull out the tray hook as far as possible.
No.
Name
1
T
ray hook
1
1
111
113
