Product overview RJ-900X series OPERATION MANUAL
2-6
2.2.4 Rear section (RJ-900X)
No. Name Function
1
AC inlet Power cable plug is correctly inserted in the socket.
2
Network interface connector It is the connector which connects the network interface cable.
3
USB connector It is the connector which connects the USB2.0/1.1 cable.
4
Scroller receiver Scroller is set when using roll media.
5
Media feed slot It is the slot for feeding media.
6
Ink cartridge slot It houses the ink cartridge.
To Next Page
