• When the Command item on Command Menu is set to "MH-GL/2", the following setting of the
setup item becomes disabled.
• Origin Menu
• For the operation of the setting menu, refer to “
4.5.2 Menu Setup Procedure”.
Setup item Setting value Description
Command <MH-GL, GL/2> Condition setup of printer command which is sent from
a PC to the printer is performed.
MH-GL/2
Origin <Center>
• Origin point of print data is set.
• Center: Center of hard clip
• LL: Bottom left point of hard clip
LL
Step <0.025 mm> The step of software resolution at printing is set.
0.010 mm
Position
<P1>
The initial print position on printing is set.
• P1: Initial point of scaling
• LL: Bottom left point of hard clip
• Full: Bottom left point of media
LL
Full
Terminator Normal The function at the print finish time on printer
command included in print data is set.
• Normal: Only the primary function of printer
command is used.
• Special: SP0; (SP;) command is recognized as the
finish of data.
<Special>
ImageReso. 300 dpi / <360 dpi> / 600
dpi / 720 dpi / 1200 dpi /
1440 dpi
The resolution when printing image data is set.
OnlineTimer Off The time from the break of receiving print data from PC
to recognize the finish of print data is set.
2 s to <30 s> to 800 s
Merge <Last> Sets the printing method for overlapping area in the
printing data.
Mix
Quality <ThinLine> Sets the priority given on figures for printing in the
printing quality on printing.
FillIn
