Maintenance RJ-900X series OPERATION MANUAL
5-8
5. Hold the movable flange, and tap the scroller as illustrated below to remove the movable flange.
NOTE
• When removing roll media, do not give a shock to the left end of the scroller (movable flange side)
by dropping it to the floor. Doing so may damage the left end of the scroller due to the shock.
6. Remove roll media from the scroller.
7. For loading other roll media, follow the instructions below.
TIP
• For loading the roll media, refer to "3.4 Media handling".
• For roll media you do not use, store it according to "
4.2.3 Precaution on storing media".
No. Name
1
Roll media
2
Scroller
No. Name
1
Roll media
2
Scroller
2
1
2
1
