• The operation keys are assigned with functions and names which change with printer status
(Normal or Setup menu display). For details on printer status, refer to "
2.3 Printer status".
No. Name Normal Setup menu display
1
[Menu] key Changes to Setup menu. Shifts from Setup menu display to
Normal.
2
[Enter] key -
• The menu to set is selected and it
shifts to the next hierarchy.
• The value is determined and saved.
[Cleaning] key The printer head will be cleaned, if
this key is continuously pressed for
two seconds or more.
-
3
[Cancel] key
• During printing: Printing is
forcefully terminated and one file of
the remaining data is deleted.
• During receiving/analysis: Data that
is already received and analyzed is
deleted and one file of subsequent
receiving data is ignored.
• Ink dry timer wait: Ink dry timer
wait is canceled and the media is
discharged.
• Returns to the previous menu
hierarchy. Change in the setup
value becomes invalid.
• Shifts from Setup menu display to
Normal.
[Cut] key Before data receiving when roll media
is set, cut the roll media at that
position.
-
4
[Back] key Media type is set.
• Lamp of media setup lights up
(green).
Menu is changed to reverse feeding.
5
[Next] key Printing and color mode are set.
• The lamps of printing mode and
color mode that is set light up
(green).
Menu is changed to forward feed.
6
[Backward feed] key Media is fed in reverse direction. -
[Setting value +] key -
• The value is changed to forward
direction.
• The value is increased during
numerical input.
7
[Forward feed] key Media is fed in the forward direction. -
[Setting value-] key -
• The value is changed to reverse
direction.
• The value is decreased during
numerical input.
8
[Power] key The printer is turned on or off. The printer is turned on or off.
