26 of 43
GT20 Wire and Programming Manual www.NabcoEntrances.com
P/N C-00140 Rev 5-7-18
SECTION 91: The Home Page
>##<
E50
DN 1253
TOP HALF
BOTTOM HALF
911 Top Half of Home Page
X
X
Table 6
Display Description Display Description
<REF?> Waits for reference switch << >> Opening
< ?? > Unknown < > Open
>< Closed >> << Closing
>##< Closed and locked == Stopping
Table 7
Display Description Display Description
OEO Exterior acvaon sensor (Exterior Acvaon Signal) SER Push side door mounted sensor (Approach
Side Safety Signal)
OEI Interior acvaon sensor (Interior Acvaon Signal) SEF Door mounted sensor for obstacle detecon
(Recycle Sensivity)
KEY Acvaon device for NIGHT mode (External Switch Acvaon
Signal, Keyswitch, Card Reader, etc.)
EMY-IN Emergency Open Input (Emergency Input
Signal)
SES Swing side door mounted sensor (Swing Side Safety Signal) PUGO Push-and-Go
PRE Header Mounted Sensor on Swing Side
912 Boom Half of Home Page
X
X
will display on the lower right hand corner.
Table 8
# Description
1 Program Mode (Selector Buon).
KEY
s E50
DN 1260
①
②
③
Swing door: in Night Mode; is opening; and communicang to
a Slave door; (1) System Error
2 X (m) means closing sequence - Master
X (s) means closing sequence - Slave
X (w) means Interlock
3 Acve error
To Next Page
