GT20 Wire and Programming Manual www.NabcoEntrances.com
P/N C-00140 Rev 5-7-18
CHAPTER 4: 120 VAC GENERAL WIRING
Shut the installaon site, branch Circuit Breaker OFF Failure to do so may result in serious
personal or fatal injury When uncertain whether power supply is disconnected, always
verify using a voltmeter
All high voltage electrical connecons must be made by licensed electricians according to
Naonal and Local electrical codes/regulaons
Permanent wiring shall be employed as required by local codes
Keep all Incoming 120 VAC wiring separate from low voltage wiring within Header 120 VAC
Power wires must be routed (separate from other wiring) located near the top of inside Header
Ensure that the Grounding of the Electric Power Supply is installed/connected in a proper way
(especially the PE Cable from the Building Side)
All cable used for eld wiring from a Class 2 circuit of an operator to an external device shall be:
a Type CL2, CL2P, CL2R, or CL2X complying with the Standard for Power Limited Circuit Cables,
UL 13, or
b Other cables with equivalent or beer electrical, mechanical, and ammability rangs
Aenon: Depending upon the installaon, the Power Switch/Program Selector may have to be installed
on the opposite side of the Header If 120 VAC Power wires must be installed from Hinge Side of
Header, ensure all wires are securely clipped to prevent pinching of the wires during the Motor/
Operator installaon process
Aenon: Electrical circuit to Nabco operator must not be not shared with other equipment such as lighng,
cash registers, or any device that might cause electrical interference on the circuit
Aenon: Insert all Incoming 120 VAC Power wires into the pre drilled Electric Service Access Hole located at
the le or right side of Header End Cap
Note: It is recommended for the Installer to house all Incoming 120 VAC wires within an Electrical Conduit.
1. Connect the Main Power Supply.
2. Mount the Side Cover.
DN 1177
~2 Cable
L = Live Wire
N = Neutral Wire (Common)
PE = Ground Wire
PE Cable
~1 Cable
Use Copper
Conductors Only
PC-ABS
0548-407
L Cable
N Cable
PE Cable
Figure 1 
DANGER
WARNING
CAUTION
CAUTION
CAUTION
CAUTION
