Nabco GT20 Wire And Programming Manual

32 of 43
GT20 Wire and Programming Manual www.NabcoEntrances.com
P/N C-00140 Rev 5-7-18
Table 16 
Element
Description
FACTORY RESET All sengs that were programmed into the Control will be reset to Factory Defaults.
PARAM RESET Resets/Sets all moon Parameters back to the default values (inclusive opening angle, rod assemblies,
Invers and dAxix).
CONFIG RESET Resets all conguraon sengs back to the default values.
DOUBLE RESET Resets simultaneous pair sengs and airlock sengs back to the default values.
Table 17 
Menu
Description
Block? To lock the Joysck Press OK for 2 seconds The Display shows temporarily BLOCK!
UBLOC? To unlock the Joysck Press OK for 2 seconds The Display shows temporarily UBLOC!
BlockD When the Joysck is blocked, the "Home display" shows BLOCKD, if the Joysck is operated!
Table 18 
Element
Description
Update SW Updates the latest version of soware.
Table 19 
Element
Description
TEACH OK? Programs the Setup Procedure within the GT20 Control.
CHAPTER 10: DOUBLE SWING DOORS
DN 1183
Master Door Panel:
Opens fi rst; Closes second
Slave Door Panel:
Opens second; Closes fi rst
Master Operator Assembly
Slave Operator Assembly
Figure 5 
SECTION 101: Acvaon Input Connecons:
Acvaon Inputs:
X 
X 
X 
Connected to the:
X 
X 
