Nabco GT20 Wire And Programming Manual

30 of 43
GT20 Wire and Programming Manual www.NabcoEntrances.com
P/N C-00140 Rev 5-7-18
Element
Default Value Description
LockAU UNLOCK U N L O C K /
LOCK
X Sets the condion of the lock when in Automac mode.
X Only visible when Unlock is set to PERMAN
LockEX LOCK U N L O C K /
LOCK
X Sets the condion of the lock when in EXIT mode.
X Only visible when Unlock is set to PERMAN
LockMA UNLOCK U N L O C K /
LOCK
X Sets the condion of the lock when in MANUAL mode.
X Only visible when Unlock is set to PERMAN
LcdDir 0 0...1 Orientaon of the display (LCD direcon)
MovCon OFF OFF/ON Endurance test Open/Close (moving connuous)
Pre Sen N.C. OFF/N.C./
N.O.
Swing side presence sensor output logic
OExMAN ON OFF/ON X ON” enables acvaon to reopen the door during the closing cycle of a manual opening.
X 
The following Table is only displayed when an optional Relay Board is installed
RC 0.1
RC 0.2
RC 0.3
RC 0.4
CLOSED
OPEN
ERROR
GONG
Only (1) PCB Terminal per Switch Acvaon is allowed. For example (2) acvaons (during closing and
opening) must be wired to (2) dierent PCB Terminals.



CLOSED Relay switches when the Door Panel is fully closed.
OPENING Relay switches when the Door Panel is opening.
OPEN Relay switches when the Door Panel is fully open.
CLOSING Relay switches when the Door Panel is closing.
ERROR Relay switches if the GT20 Control detects an Error(s).
PSAUTO Relay switches when the Program Selector is in Mode: AUTOMATIC
PSNIGHT Relay switches when the Program Selector is in Mode: NIGHT
PSEXIT Relay switches when the Program Selector is in Mode: EXIT
PSOPEN Relay switches when the Program Selector is in Mode: OPEN
PSMANU Relay switches when the Program Selector is in Mode: MANUAL
GONG Relay switches momentarily during the me the GT20 Control recieves a signal from:
Terminal 12 and Terminal 13 (Opening Command Inside).
LOCKED Relay switches during the me the Door Panel is LOCKED with an electric lock.
Table 12 
Element Default Value Description
DubleD OFF MastrA
SlaveA
Determines closing sequence in case of Simultaneous Pair with Astragal.
AoSeq 0 0...110 X Delay angle for opening sequence for Slave Door.
X Only visible on Slave Control when DubleD is not OFF
AcSeq 0 0...110 X Delay angle for closing sequence for Master Door.
X Only visible on Master Control when DubleD is not OFF
TcSeq 1.5 0...3.0 X Time delay for closing sequence for Master Door.
X Only visible on Master Control when DubleD is not OFF
InterL OFF OFF
Side A
Side B
Two individual door Panels that are connected by CAM Bus. One Door Panel cannot open if
the other door is open. Also known as AirLock or Mantrap.
ILAuto Acve Acve
Inacve
X Airlock funconality works in Automac mode.
X Only visible if InterL is not OFF
