GT20 Wire and Programming Manual www.NabcoEntrances.com
P/N C-00140 Rev 5-7-18
Element
Unit Type Default Value Description
FWind Full & Low OFF OFF X Obstacle detecon opmized for exterior doors (wind loads).
X Assuming that a gust of wind is not a hard obstacle which will stop the door,
the motor current will rise “slowly”. In this case the GT20 Control will provide
addional power to connue the door movement.
X When FWind is turned ON, Nabco strongly recommends the use of door
mounted sensors to stop or re-open the door if an obstacle is detected during
the door cycle.
OPEN
CLOSE
BOTH
Fo Full Power 4 0...9 X Opening force (force open) when an obstacle is detected during Open/Close
cycle or both.
X In standard mode Obstacle Detecon can not be switched On/O. It can be
adjusted with parameters “Fo” = Opening force (force open) and v “Fc” =
close force (force close). To make Obstacle Detecon least sensive: set both
parameters on max. (= step 9). To make Obstacle Detecon most sensive: set
both parameters on min. = 0 (cauon this can allow the drive to react to small
changes in wind).
Low Energy 9 0...9
Fc Full Power 4 0...9
Low Energy 9 0...9
Foh Full & Low 4 0...9 Hold-open force (force open hold)
Fch Full & Low 0.0A 0.0A...3.5A X Interlocking Force (force close hold): automacally programs FLock and FDelay
if these sengs are set at 0.
X If there is no electric lock and the Interlocking Force Fch is not adjusted, Error
14/02 will be displayed as a warning aer the Teach1 procedure and the Door
Panel will endlessly re-open.
LowEn Low Energy OFF OFF Door Panel is Full Power in both direcons
ON X Door Panel is Low Energy in both direcons
X Door Panel is acvated by a Knowing Act
Width Full & Low 48 30...63 Door Panel width
Weight Full & Low 200 100...550 Door Panel height
Ao Full & Low 95° 20°...190° Opening angle of the door (angle open)
Teach must be acvated aer this seng has been changed.
Rod Full & Low STD-PH STD-PH Outswing Arm and Arm Shoe Push Funcon = Right Hand
Motor Cable Connector: X = Orange
SLI-PL Inswing Arm with Track and Roller Pull Funcon = Le Hand
Motor Cable Connector: Y = Green
SLI-PH Outswing with Inswing Track and Roller Push Funcon = Right Hand
Motor Cable Connector: X = Orange
DO NOT USE
WIN-PH Not Available Not Available
DIR-PH Outswing Arm and Track; Not Available Push Funcon = Right Hand
Motor Cable Connector: X = Orange
DIR-PL Outswing Arm and Track; Not Available Pull Funcon = Le Hand
Motor Cable Connector: Y = Green
OHC-PH Overhead Concealed Push Funcon = Right Hand
Motor Cable Connector: X = Orange
OHC-PL Overhead Concealed Pull Funcon = Le Hand
Motor Cable Connector: Y = Green
Rod Full & Low STD-PH X If panic breakout latch is installed and the motor is plugged in backwards or the wrong arms
are chosen during programming, there is a possibility the door can burst open unexpectedly
towards the installer once TEACH mode is iniated.
X Teach must be acvated aer this seng has been changed.
