FPΣ
Communication Function 2 General-purpose Serial Communication
9-32
9.5.3 Setting of System Register
Thefollowingtypesofcommunicationcassettescanbeusedwith1:Ngeneral-purpose
serial communication.
Settings when using the COM. 1 port
No. Name Set value
No. 410
Unit No. 1 to 32 (Set the desired unit No.)
No. 412
Communication mode for COM.1 port General communication
No. 413
Communication format for COM.1 port Character bit: 8 bits....
Parity check: Odd.....
Stop bit: 1 bit.........
Terminator: CR......
Header: STX not exist.........
No. 415
Baud rate setting 9600 bps
No. 416
Starting address for data received Set the desired address.
No. 417
Buffer capacity setting for data received Set the desired capacity. (Max. 2,048 byte)
Settings when using the COM. 2 port
No. Name Set value
No. 411
Unit No. 1 to 32 (Set the desired unit No.)
No. 412
Communication mode General communication
No. 414
Communication format Character bit: 8 bits....
Parity check: Odd.....
Stop bit: 1 bit.........
Terminator: CR......
Header: STX not exist.........
No. 415
Baud rate setting 9600 bps
No. 418
Starting address for data received Set the desired address.
No. 419
Buffer capacity setting for data received Set the desired capacity. (Max. 2,048 byte)
The communication format and baud rate (transmission speed) should be set to match
the connected device.
