FPΣ
13.12 Dimensions
13 - 69
13.12 Dimensions
13.12.1 Control Unit
FPG-C32T, FPG-C32T2
30.0/1.181
90.0/3.543
60.0/2.362
(18/0.709)
3.5/0.138
4.5/0.177
(unit: mm/in.)
FPG-C24R2
30.0/1.181
90.0/3.543
60.0/2.362
3.5/0.138
4.5/0.177
10/0.394
(unit: mm/in.)
