NAiS FP Series User Manual

FPΣ
Self-Diagnostic and Troubleshooting
12 - 4
12.1.2 Operation on Error
Normally, when an error occurs, the operation stops.
Theuser mayselectwhether operation is to be continuedor stoppedwhen a duplicated
output error or operation error occurs, by setting the system registers. You can set the
error which operation is to be continued or stopped using the programming tool
software as shown below.
“PLC Configuration” setting menu on programming tool software (FPWIN GR)
To specify the steps to be taken by the FPWIN GR if a PLC error occurs, select “PLC
Configuration” under “O
ption” on the menu bar, and click on the “Action on Error” tab.
The screen shown below is displayed.
Figure 229: FPWIN GR PLC Configuration setting screen
Example 1: Allowing duplicated output
Turn off the check box for No. 20. When operation is resumed,
it will not be handled as an error.
Example 2: When continuing operation even a calculation error has occured
Turn off the check box for No. 26. When operation is resumed,
it will be continued, but will be handled as an error.
