FPΣ
Self-Diagnostic and Troubleshooting
12 - 8
12.2.4 If Outputting does not Occur as Desired
Proceed from the check of the output side to the check of the input side.
Check of output condition 1: Output indicator LEDs are on
Procedure 1
Check the wiring of the loads.
Procedure 2
Check if the power is properly supplied to the loads.
- If the power is properly supplied to the load, there is probably an abnormality in the
load. Check the load again.
- Ifthepowerisnotsuppliedtotheload,thereisprobablyanabnormalityintheoutput
section. Please contact your dealer.
Check of output condition 2: Output indicator LEDs are off
Procedure 1
Monitor the output condition using a programming tool.
- If the output monitored is turned on, there is probably a duplicated output error.
Procedure 2
Forcing on the output using forcing input/output function.
- If the output indicator LED is turned on, go to input condition check.
- If the output indicator LED remains off, there is probably an abnormality in the
output unit. Please contact your dealer.
Check of input condition 3: Input indicator LEDs are off
Procedure 1
Check the wiring of the input devices.
Procedure 2
Check that the power is properly supplied to the input terminals.
- If the power is properly supplied to the input terminal, there is probably an
abnormality in the input unit. Please contact your dealer.
- If the power is not supplied to the input terminal, there is probably an abnormality
in the input device or input power supply. Check the input device and input power
supply.
To Next Page
