NAiS FP Series User Manual

FPΣ
13.2 I/O No. Allocation
13 - 11
I/O No. of FP0 A/D converter unit (for right side expansion)
TheI/O allocation of FP0A/D converter unit(FP0-A80) isdetermined by theinstallation
location.
The data of the various channels is switched and read using a program that includes
the flag for switching converted data.
Unit First
expansion
Second
expansion
Third
expansion
Input CH0, CH2, CH4, and
CH6: each 16 points
WX2
(X20 to X2F)
WX4
(X40 to X4F)
WX6
(X60 to X6F)
CH1, CH3, CH5, and
CH7: each 16 points
WX3
(X30 to X3F)
WX5
(X50 to X5F)
WX7
(X70 to X7F)
I/O No. of FP0 I/O link unit (for right side expansion)
The I/O allocation of FP0 I/O link unit (FP0-IOL) is determined by the installation
location.
Unit First
expansion
Second
expansion
Third
expansion
Input: 32 points X20 to X3F X40 to X5F X60 to X7F
Output: 32 points Y20 to Y3F Y40 to Y5F Y60 to Y7F
