FPΣ
Specifications
13 - 24
Relay No. Name Description
R9030 Not used
R9031 Not used
R9032 COM. 1 port communication
mode flag
This is on when the general-purpose communication function is
being used.
It goes off when the MEWTOCOL-COM or the PLC link function is
being used.
R9033 Print instruction executionflag Off: Printing is not executed.
On: Execution is in progress.
R9034 Run overwrite complete flag This is the special internal relay that goes on for only the first scan
following completion of a rewrite during the RUN operation.
R9035 Not used
R9036 Not used
R9037 COM.1 port communication
error flag
This goes on if a transmission error occurs during data
communication.
This goes off when a request is made to send data, using the F159
(MTRN) instruction.
R9038 COM.1 port reception done
flag during general purpose
communicating
Turns on when the end code is received during the general purpose
communicating.
R9039 COM.1 port transmission
done flag during general
purpose communicating
This goes on when transmission has been completed when using
general-purpose communication.
It goes off when transmission is requested when using general-
purpose communication.
R903A High-speedcounter
control flag
ch0 Turns on while the high-speed counter instructions F166 (HC15),
F167 (HC1R) and the pulse output instructions “F171 (SPDH) to
F176 (SPCH)” are executed.
R903B High-speedcounter
control flag
ch1 Turns on while the high-speed counter instructions F166 (HC15),
F167 (HC1R) and the pulse output instructions “F171 (SPDH) to
F176 (SPCH)” are executed.
R903C High-speedcounter
control flag
ch2 Turns on while the high-speed counter instructions F166 (HC15),
F167 (HC1R) and the pulse output instructions “F171 (SPDH) to
F176 (SPCH)” are executed.
R903D High-speedcounter
control flag
ch3 Turns on while the high-speed counter instructions F166 (HC15),
F167 (HC1R) and the pulse output instructions “F171 (SPDH) to
F176 (SPCH)” are executed.
R903E Not used
R903F Not used
